Coreless Roll Up with Rewind

High Speed, Auto Cut-Off

The Rosenthal Coreless Roll Up with Rewind system is a high-speed, semi-automatic system ideal for quickly converting large master rolls of paper and board into manageable 50-foot or 100-foot rolls. With this machine, you’ll be able to easily unwind and rewind your materials to any desired length onto a slotted drum. You can have product information or logos printed onto your materials at the same time with our Printing add-on.

Browse all our add-ons below, which include Slitting and Fully Automatic options.

Materials

The Rosenthal Coreless Roll Up with Rewind will work with most flexible materials, including:

  • Fabric
  • Felt
  • Fiberglass
  • Film
  • Foil
  • Paper
  • Prepreg
  • Pressure Sensitive Vinyl
  • Rubber

Please contact us to send a sample roll for testing, or if you have any questions about your material’s suitability.

Specifications

Unit PriceStarting at $140,000
Maximum Web Width36″, 48″, 60″, 72″, 84″, 96″
Maximum Web SpeedUp To 200 Feet Per Minute
Cutting MethodReciprocating Razor Cut
Repeatability+/- .1%
Feed LengthInfinitely Adjustable
ControlPLC With Color Touchscreen
RewindCoreless Rewind
Maximum Master Roll Weight2,000 lbs, 4,000 lbs, 10,000 lbs

Disclaimer: Specifications are subject to change. Performance is material-dependent as the machine stops to cut, and maximum feed speed is affected by material characteristics. Please request a quote for more detailed information, or learn more about our custom order options.

Add-On Options

Slitting

Razor, Score, or Shear

Printing

Inkjet Printing of Logo or Product Information

Auto Roll Start

Fully Automatic Operation

Videos

Coreless Roll Up System

Coreless Roll Up with Rewind

Image Gallery
