Roll Slitter

Slit Rolls Fast, Save Time

The Rosenthal Roll Slitter is the perfect choice to accurately, easily, and economically slit your stock width rolls into desired widths in just a few minutes. A stationary, multi-blade design ensures cuts exactly as you want them, all without needing to unwind or rewind your materials.

Designed and built in the USA, our Roll Slitter’s space-saving design with simple operation enables easy integration with your existing equipment. A low maintenance system, with a durable all-welded heavy-duty steel frame, the Rosenthal Roll Slitter is built to last and handle all types of production environments.

The Rosenthal Roll Slitter is built-to-order and available in a variety of web width and unwind capacities.

Roll Slitter

Model: RS (SmartSlitters Genesis)

The Rosenthal Roll Slitter has a range of add-ons and additional features available, such as Dual Blade Configurations and Rewinding features.

Materials

The Rosenthal Roll Slitter will work with most flexible materials, including:

  • Felt
  • Film
  • Paper
  • Pressure Sensitive Vinyl
  • Rubber
  • Tape

Please contact us to send a sample roll for testing, or if you have any questions about your material’s suitability.

Specifications

Unit PriceStarting at $10,000
Maximum Roll Outer Diameter (OD)8″ or 12″
Maximum Web Width62″, 74″, 98″, 126″, 197″
Mandrel SpeedUp To 400 Rotations Per Minute
Slitting MethodRound Blade
Cantilevered Mandrel Diameter3″, 2″
Roll LockingPatented Lift and Lock Expansion Ring
Blade DepthAdjustable Manual Stop

Disclaimer: Specifications are subject to change. Performance is material-dependent as the machine stops to cut, and maximum feed speed is affected by material characteristics. Please request a quote for more detailed information, or learn more about our custom order options.

Add-On Options

Roll Loading

Roller Table

Variable Speed Drive

Up To 400 Rotations Per Minute

Roll Stand

Cantilevered or Drop-in Shaft

Heavy Duty Legs with Locking Casters

3” x 3” Legs for Added Stability

Drop-In Mandrel

For Heavy Rolls

Digital Yardage Counter with Auto-Stop

Rewind with Optional Variable Speed and Unwind

Lathe-Style Chuck

For Small Inner Diameter (ID) Cores

Videos

Roll Slitter

Roll Slitter – 3M Reflective Vinyl

Image Gallery

Roll Slitter with Band Blade

Designed For Large Rolls

Model: RSB

The Rosenthal Roll Slitter with Band Blade is the perfect solution for your large outer diameter (OD) roll slitting requirements. Securely lock your roll into place with the patented Lift and Lock Expansion Ring, and then manually slit your rolls layer-by-layer down into the core, without needing to unwind or rewind your materials.

This time-saving machine can be equipped with various band blades or a diamond blade, giving it the ability to slit a wide variety of materials and meet your needs.

The Roll Slitter with Band Blade is built-to-order and is available in various web width and outer diameter (OD) capacities. Achieve greater efficiencies by selecting additional features, such as Rewind and Dual Blade configurations, or one of the add-on options.

Materials

The Rosenthal Roll Slitter with Band Blade will work with most flexible materials, including:

  • Fabrics
  • Felt
  • Fiberglass
  • Foam
  • Non-Wovens
  • Rubber
  • Vinyl

Please contact us to send a sample roll for testing, or if you have any questions about your material’s suitability.

Specifications

Unit PriceStarting at $24,000
Maximum Roll Diameter20″
Maximum Web Width62″, 74″, 98″, 126″, 197″
Mandrel SpeedUp To 400 Rotations Per Minute
Slitting MethodBand Blade
Cantilevered Mandrel Diameter3″, 2″
Roll LockingPatented Lift and Lock Expansion Ring
Blade DepthAdjustable Manual Stop to Prevent Blade Damage

Disclaimer: Specifications are subject to change. Performance is material-dependent as the machine stops to cut, and maximum feed speed is affected by material characteristics. Please request a quote for more detailed information, or learn more about our custom order options.

Add-On Options

Roll Stand

Cantilevered or Drop-In Shaft

Drop-In Mandrel

For Heavy Rolls

Cradle Mandrel

For Wide Rolls

Lathe-Style Chuck

For Small Inner Diameter (ID) Cores

Videos

Rosenthal Roll Slitter with Band Blade

Rosenthal Roll Slitter with Band Blade for up to 20 inch OD rolls

Image Gallery

Roll Slitter with Unwind

Roll Slitting and Rewinding in One

Model: RSW (SmartSlitters Super)

The Rosenthal Roll Slitter with Unwind can slit hundreds of different kinds of roll-stock materials. Our Roll Slitter with Unwind also features rewinding capabilities, which allow you to increase efficiency and minimize downtime through transferring a precise amount of material from a master roll onto a new core.

Securely lock your roll into place with the patented Lift and Lock Expansion Ring, and then slit your rolls layer-by-layer down into the core, without needing to manually unwind or rewind your materials. Load a roll onto the unwind and place an empty core on the mandrel and you can rewind all or a portion of your master roll.

Designed and built in the USA, Rosenthal Roll Slitters have an all-welded heavy-duty steel frame that is built to withstand just about anything you throw its way, delivering you years of dependable service.

The Roll Slitter with Unwind is built-to-order and is available in various web width and outer diameter (OD) capacities. For those looking to further boost efficiency, explore our Cantilevered Unwind, Dual Blade Configuration, and other add-on options.

Materials

The Rosenthal Roll Slitter with Unwind will work with most flexible materials, including:

  • Felt
  • Film
  • Paper
  • Pressure Sensitive Vinyl
  • Rubber
  • Tape

Please contact us to send a sample roll for testing, or if you have any questions about your material’s suitability.

Specifications

Unit PriceStarting at $13,000
Maximum Roll Outer Diameter (OD)8″ or 12″
Maximum Web Width62″, 74″, 98″, 126″, 197″
Mandrel SpeedUp To 400 Rotations Per Minute
Slitting MethodRound Blade
Cantilevered Mandrel Diameter3″, 2″
Roll LockingPatented Lift and Lock Expansion Ring
Blade DepthAdjustable Manual Stop
Heavy-Duty LegsFor Added Stability

Disclaimer: Specifications are subject to change. Performance is material-dependent as the machine stops to cut, and maximum feed speed is affected by material characteristics. Please request a quote for more detailed information, or learn more about our custom order options.

Add-On Options

Roll Loading

Roller Table

Roll Stand

Optional Cantilevered Unwind

Drop-In Mandrel

For Heavy Rolls

Digital Yardage Counter with Auto Stop

Rewind with Optional Variable Speed and Unwind

Lathe-Style Chuck

For Small Inner Diameter (ID) Cores

Dual Blade Configuration

For Double the Cuts

Videos

Roll Slitter with Unwind

Image Gallery
